Smokeless Eco

Basic Info.

Packaging & Delivery

Product Description

Smokeless garbage incinerator for household garbage medical hospital waste

Product Description

1.Simple and convenient operation, high burning temperature and burning of organic matter removal rate was 99%, Fast burning speed, effectively.Covers an area of small, low cost, low malfunction,easy maintenance.2.The Incinerator suitable for the hospital medical waste, life rubbish, dead animals, the villages and towns of urban garbage disposal and so on various aspects non-hazardous wastes treatment equipment.
3.The incinerator consists of combustion chamber,combustion chamber fan,cinder box,secondary combustion chamber,diesel burner,diesel oil storage tank,diesel transmission pipeline,filter dust removal chamber,water curtain dust removal flue,smoke exhaust flue,circulating water tank,circulating water pipeline,smoke exhaust fan,smoke exhaust pipeline (chimney)and control system.
4.The incinerator is a waste incineration treatment equipment with independent intellectual property rights developed by Weifang Zhite Environmental Protection Co., LTD., which introduced the world's advanced incinerator technology and organized technical experts to
tackle key problems.With fully enclosed, small size, high incineration efficiency, reasonable process, leading technology and high degree of harmless characteristics, is the ideal waste treatment equipment of all kinds of hospitals, hotels, stations, livestock farms, large commercial institutions, enterprises, institutions.

Product Parameters

Process Flow

1.The incineration process adopted by this series of incinerators is currently the most advanced combustion mode of primary pyrolysis, gasification and surround air mixed combustion + secondary mixed incineration burnout treatment.
2.The design of the primary combustion chamber of the incinerator adopts the technology of pyrolysis gasification mixed combustion around the air to make the temperature in the incinerator go from 200ºC to 400ºC, and there will be no frit, slag block, sintering and other problems in the incineration process. Compared with the direct combustion furnace and other furnaces, the dust production of pyrolytic gasification wraparound air mixed combustion furnace is very small.
3.The secondary incineration burner and circumferential air feeder are arranged in the secondary mixed incineration burnout chamber. At high temperature, the combustible gas in the flue gas can be fully burned, and the gas produced by pyrolysis gasification around the air mixing chamber can be fully mixed with air in an efficient way to prevent the carbon in the gas flame from spilling out and the occurrence of late combustion. The residence time of the incinerator flue gas in the furnace is about 2 seconds, so that the combustible gas in the flue gas and the combustible material in the fly ash are completely incinerated.
4.When the flue gas enters the secondary mixed incineration chamber, tangential entry and tangential entry of combustion-supporting air are used to support the combustion, so that the flue gas can be fully burned again in the burning-out chamber. At the same time, the rotating air flow is used to dust the flue gas. The upper part of the incinerator is equipped with a water curtain dust removal type tail gas purification equipment, and the components of the odor in the flue gas are decomposed at high temperature. Through the dust removal room filtration, water curtain dust removal adsorption treatment, to achieve the adsorption of acid gas, exhaust purification purposes. The harmful components in the flue gas are reduced to the national "Hazardous waste incineration pollution control Standard (GB18484-2001)" and other standard regulations below the value.
5.The operation control of the incinerator adopts automatic program control, which reduces the labor degree of the workers. The design of the incinerator door and the ash cleaning door adopts the fully sealed structure in the form of the child and the mother. During the incineration, the inside and outside of the furnace are completely isolated, forming negative pressure combustion and eliminating the possibility of secondary pollution. In particular, the treatment of infectious and dangerous medical waste can highlight its unique advantages.

Detailed Photos

Equipment characteristics

Other product

Customer visit

Company Profile

ZHITE Environmental Protection Technology Co., Ltd. Which located in the "International kite Capital",Weifang city,Shandong Province.With beautiful environment and convenient transportation,it's the domestic environmental protection equipment professional manufacturers.With an area of more than 20,000 square meters,the company adopts modern enterprise management philosophy,seiko manufacturing,forge ahead. And the company has strong technical force,advanced technology,complete varieties,in strict accordance with ISO9001 standards,organization,design,production,sales and management.The company is a comprehensive domestic enterprise with integrating scientific research and development,engineering design,production and installation and commissioning services.The main products are medical waste treatment equipment,diseased livestock and poultry harmless treatment equipment,household waste treatment equipment,kitchen waste treatment equipment,tail vegetable treatment equipment,sludge treatment equipment and all kinds of shredding equipment and other solid waste treatment products. Also can design and customize all kinds of efficient and practical equipment and production lines according to customer needs.
